• Monobloc or two pieces body
• Seat with rigid ring

• Split shaft with low pressure drop
• Wide range of materials

Monobloc body:

• Available for wafer, lug or flanged style
• To ensure maximum security and reliability
• Available with extended neck to enable piping insulation
• Wafer style body with shaped ring to ease valve installation and centering within the pipe flanges

Two pieces body:

• Design to allocate PTFE seat ring

Disc:

• Design to minimize pressure drop
• Polished sealing area in the entire perimeter to provide total sealing and ensure low operating torque

Shaft:

• Upper shaft transmits the rotation movement to the disc by means of square drive up to 10” eliminating the existence of taper pins, keys and studs, removing the possibility of wear and leakage by there parts; upper shaft fixed to the body through a spring pin, defining the “anti extrusion” system, avoiding the shaft being extruded from the body
• Lower shaft fixed to the body through a spring pin, defining the Trunnion system of the set, ensuring perfect alignment between body, disc and shaft

Actuation:

• Top flange allows easy coupling to manual, pneumatic and electric actuators
• ISO 5211 standard
